Aqara Video Doorbell
The Aqara G4 is a unique video caller that can be wired or battery powered. It is also the first battery-powered option that works with Apple's HomeKit Secure Video and supports streaming to Google and Alexa smart displays, equipped with local AI used for facial recognition alerts, automation and more.
Key features of Aqara Smart Video Doorbell G4
- Built-in local artificial intelligence
- Compatibility with Apple Home Kit
- Streaming camera video to Google and Alexa monitors
- Free cloud and local storage
- Richly equipped outdoor unit
- Powered by batteries or wired
- Wi-Fi repeater and bell (chime) in one
- Rich set of configuration options
Local AI face recognition
The built-in local facial recognition algorithm is the biggest advantage of the Aqara doorbell. It can help people quickly learn the identity of the person in front of the door by noting the name of a specific face and sending a notification via the app, or by setting different automations based on a specific person. Even if the network is sometimes disconnected, the recognition function will not be affected.
Doorbell specifications |
|
| Model | SVD-C03/4 |
| Video resolution | 1080p |
| Viewing angle | 162° (diagonal) |
| PIR detection angle | Horizontal 120°, vertical 80° |
| Wireless protocols | Wi-Fi IEEE 802.11 b/g/n 2.4 GHz |
| Battery | 6 * LR6 AA alkaline battery (replaceable) |
| Wired input | 12V-24V AC 0.2A 50/60Hz 8V-24V DC 0.5A |
| Operating temperature | -18°C ~ 50°C (-0.4°F ~ 122°F) |
| Operating humidity | 0 ~ 95% RH, non-condensing |
| Siren specifications | |
| Model | SVD-C03/4 |
| Speaker power | 2 W |
| Wireless protocols | Wi-Fi IEEE 802.11 b/g/n 2.4 GHz WPA3 |
| Ports | USB-C, usable and recommended to use 5V USB DC UPS |
| Input power | 5 V⎓1 A |
| Total power consumption | 5 W |
| Local storage | Support for up to 512 GB of local memory in the form of a microSD card |
| Operating temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Operating humidity | 0 ~ 95% RH, non-condensing |
| Video parameters | |
| Codec | H.264 |
| Number of frames per second | 1080p@20fps/720p@20fps/360p@20fps |
| Audio parameters | |
| Audio | AAC encoding, two-way voice |
| Other parameters | |
| Colour | Black |
| Authentication | CE, EAC, UKCA, FCC, IC, KC, RCM, RoHS |
| Dimensions (main module) | 141.5×65×30.4mm |
| Net weight of the bell | 163g (without battery) |
| Repeater (siren) size. | 65.2×65×28.4mm |
| Net weight of the siren | 68g |
| Box size | 148×96×73mm |
| Gross weight | 550g |
| Installation | The outdoor bell can be mounted on the wall, and the indoor unit can be mounted on the wall or placed on a flat surface. |
| Contents of the box | Smart Video Doorbell G4 x1, Chime Repeater x1, AA battery x6, user manual x1, screwdriver x1, set of screws and wall anchors x1, 20° wedge bracket x1, set of wedge screws x1, chime cable x1 |
